* Mobile cyclone dust extractor suitable for small to medium sized trade workshops.
* Able to connect to two machines by 2 x 100mm adaptor.
* Nice and quiet operation
* Automatic filter cleaning for consistent airflow.
* A manometer gives a quick, visual indication of performance.
* The wheeled waste bin makes the task of waste disposal easier
* All round extractor, able to cope with all but the largest machines.
* Supplied with 1micron polyester cartridge filter, plastic collection bag and steel impeller.
* Digital screen on control box shows its working way that the machine could be settled to stop at 2/4/6/8 hours or “L” for long time working
* 2-pieces seperated packaging or naked packaging but fully assembled are the 2 packagings we supply as standard
* Fully assembled and packed in 1 plywood case is optional
This efficient cyclone extractor has a two stage airflow system with higher airflow, removing around 99% of the waste from the airstream.
The vast majority of the waste is collected in the drum, with the cartridge filter trapping the very fine dusts.
01) Motor Power: 3000W
02) Fan diameter:402mm
03) Inlet diameter:200mm
04) Number of intake holes:3x100mm
05) Air speed:2850m3/h
07) Cartridge Filteration size:Φ370 dia×705mm height
08) Cartridge Filteration rate:99% at 1 micro
09) Collection drum size:620mm diax470mm height
10) Collection drum volume:0.138m3
11) Collection bag size:621x650mm+370x750mm
12) Over size:1343x900x1827mm
13) Packing size(mm):1350×745×1150/1250×500×510
14) N/G weight:126/166kg;37/40kg
15) 20'Container:17 units
Spare accessories:
Spare Cartridge filter: FM400A-10
Spare Plastic bag for Cartridge filter: DCA-2-P750
Spare Plastic bag for Collection drum: DCA-2-P650
