* Ideal device for extraction of sawdust, milling chips and wood shavings
* Connect to stationary or mobile wood working machines
* Increases performance of your wood working machines immensely
* Maximum extraction force at minimum space requirements
* Aerodynamically shaped, plastic fan wheel for top suction
* Powerful motor and fan wheel for optimal extraction force
TECHNICAL SPECIFICATIONS：
1) Motor power(w):550
2) Fan diameter (mm):295
3) Inlet diameter (mm):100
4) Number and diameter of intake holes (mm):1X100
5) Filter bag size (mm) diameter X height:400X670
6) Collection bag size (mm) diameter X height (cotton bag):400X670
7) Filter bag area (m2):0.8415
8) Collection bag volume (m3):0.079
9) Negative pressure (KPA) 50HZ:1.8
10) Air speed (m3/h) 50HZ:620
11) Noise (dB) LpA:89.6
12) Overall size (mm):940X500X1540
13) Packing size (mm):880X515X450
14) N.G. weight (kgs):26/29
15) Units/20' container:140
Standard accessories:Tube 2,0 m + Filter bag + Waste bag + A100/70/45/40/35 5PCS SET ADAPTORS
More Accessories
