* A stand-alone, unpowered, cyclone dust collector/interceptor.

* It is designed to be used with a standard High Volume Low Pressure chip extractor to provide the airflow.

* Using this interceptor, you can create a wood dust and chip extractor which will handle even fine dusts from drum sanders. You can either use this unit to upgrade your current workshop chip extraction system (with the typical bag filter) or place this unit next to a drum or belt sander to intercept the fine dusts before the air stream reaches the chip extractor.

* It is fitted with 3x100mm inlet and 200mm outlets, which suit many common woodworking machines.

* We recommend using a High Volume Low Pressure chip extractor with at least a 2hp motor.

* It is not suitable for use with a High Pressure Low Volume (vacuum) type extractor.

1) Dust collection drum volume:150L

2) Dust bag size(dia x height):Ф621x650

3)  Inlet port size (mm):Ф200

4)  Inlet port four-way(mm):3xФ100

5)  Outlet port size: (mm):Ф200

6)  Overall dimensions:(mm):838X756X1423

7)  Net/gross weight (kg): 14.5/16.5+24/26+7.5/9

8)  Packaging size: (mm):720X670X805+720X670X587+860X750X110

9)  Units/20'GP:35pcs
