* Adjustable legs with the height range 750mm - 1000mm with adjustment hole every 25mm.
* Machine with auto switch control
* Compact and flat design with 750mm height, ideal for integration underneath the extension tables of panel saws
* Steel blade impeller ensures constantly high extraction performance
* 3HP induction motor, capable of delivering big air flow
* 4 casters allow total workshop mobility
* Quick and easy to swap waste bags with galvanized steel strip
01) Motor power(w): 2200
02) Motor speed (rpm)/50Hz: 2950
03) Motor speed (rpm)/60Hz: 3450
04) Fan diameter (mm): 305
05) Inlet diameter (mm): 125
06) Number and diameter of intake holes (mm): 2X100
07) Fiber Filter bag DxH (mm): 500X480
08) Plastic Collection bag DxH (mm): 500X639
09) Filter bag area (m2): 0.7536
10) Collection bag volume (m3): 0.1254
11) Negative pressure (KPA): 2.2
12) Air speed (m3/h): 2200
14) Noise (dB) LpA: 87
15) Overall size (mm): 1560X560X750
16) Packing size (mm): 665x575x550; 1160x595x370
17) N.G. weight (kgs): 30/33; 21.5/25
18) Units/20' container: 58
* With Polyester fiber material filter bag + plastic collection bag fitted as standard.
