01)  Drilling capacity (chuck size): 16mm

02)  Spindle nose taper: MT2

03)  Swing: 356mm

04)  Distance chuck to upright face: 178mm

05)  Spindle travel: 80mm

06)  Levels of speed: variable

07)  Speed range: 150 to 2,300rpm

08)  Maximum distance spindle to table: 800mm

09)  Maximum distance spindle to base: 1,230mm

10)  Working table surface size:290*290mm (310mm round table optional)

11)  Working base surface size: 205 x 205mm

12)  Overall base size: 460 x 275mm

13)  Column diameter: 80mm,Collar diameter: 58mm,Quill diameter: 52mm

14)  Overall height: 1,630mm

15)  Motor power: 650W/230V

16)  Weight: 81kg

* DPT-DLX DELUXE CAST IRON TABLE FOR WOODWORKING
